TECHNICAL DETAILS
-
Length X Width X Height
2200×935×1400mm
-
Wheelbase
1479mm
-
Seat height
820mm
-
Tank capacity
20L
-
Curb weight
206kg
-
Ground clearance
210mm
-
Trail
105 mm
-
Engine type
Dual cylinders, vertical, DOHC, liquid-cooled
-
Displacement
498cc
-
Bore x stroke
72×61.2mm
-
Compression ratio
10.6:1
-
Max. power
35kW/8500rpm
-
Max. torque
45N·m/7000rpm
-
Fuel supply
BOSCH EFI
-
Max. speed
150km/h
-
Frame type
Diamond shape, dual-wing beam
-
Front suspension
KYB preload/damping adjustable
-
Rear suspension
KYB preload/damping adjustable
-
Front brake
Dual discs , 2-piston calliper/ABS
-
Rear brake
Single disc, single piston calliper/ABS
-
Front tire
110/80R19
-
Rear tire
150/70R17
-
Steering angle
35°
-
Rake
26.5°
-
Instrumention
TFT
